XFX Swift AMD Radeon™ RX 9060 XT 16GB Gaming Edition
Swiftクラスは、クリーンでエレガントなデザインを通して、現代的なエアロダイナミックスタイルを体現しています。エアフローを最大化し、冷却性能とパフォーマンスを向上させることを唯一の目的とした、考え抜かれた設計です。Swiftシリーズのグラフィックカードは、優れた冷却性能を備え、無駄を省いた驚異的なゲーミングパフォーマンスを提供します。
AMD Radeon™ RX 9060は、フルHD解像度でのゲーミングに最適化された、コストパフォーマンスに優れたGPUです。最新のAAA級タイトルを高設定で快適にプレイでき、esportsタイトルでは競技レベルの高フレームレートを実現。16GBの大容量GDDR6メモリを搭載し、将来のゲームにも余裕を持って対応します。
Swiftクラスの洗練された冷却システムは、デュアル90mmファンと最適化されたヒートシンク設計により、優れた放熱性能を実現。低負荷時にはファンが停止するゼロRPMモードを搭載し、静かな環境でのブラウジングや動画視聴も快適です。コンパクトな2スロット設計により、様々なPCケースに対応します。
画期的なチップレット技術を基盤とするAMD RDNA™ 4アーキテクチャを採用。AMD Radeon™ RX 9060は、前世代と比較して大幅に向上した電力効率と、強化されたレイトレーシング性能を実現。ミッドレンジセグメントに新たな価値をもたらします。
AMD HYPR-RXテクノロジーにより、Radeon™ Super Resolution、AMD Fluid Motion Frames、AMD Radeon™ Anti-Lagなどの機能をワンクリックで有効化。数千ものゲームで即座にパフォーマンスを向上させ、より滑らかで応答性の高いゲームプレイを実現します。
AIを活用したAMD FidelityFX™ Super Resolution 4 (FSR 4)により、画質を維持しながらフレームレートを大幅に向上。レイトレーシングを有効にした状態でも、快適なゲームプレイを実現します。ドライバーレベルで動作するRadeon™ Super Resolutionと組み合わせることで、あらゆるゲームで最適なパフォーマンスを引き出します。
1. AMD FidelityFX Super Resolution (FSR) versions 1, 2, 3, and 4 are available on select games which require game developer integration and are supported on select AMD products. AMD does not provide technical or warranty support for AMD FidelityFX Super Resolution enablement on other vendors' graphics cards. See https://www.amd.com/en/technologies/fidelityfx-super-resolution for additional information. GD-187b.
2. As of March 2023, Radeon Super Resolution (RSR) is compatible with Radeon RX 5000 series graphics and newer and works with games that support exclusive full-screen mode. AMD Software: Adrenalin Edition 22.3.1 or newer is required. For additional information, visit www.amd.com/rsr. GD-197.
3. AMD smart technologies, including AMD SmartAccess Graphics, SmartAccess Storage, SmartAccess Video, SmartShift Eco, and SmartShift Max may require OEM or developer enablement and are available with select configurations only. Select additional AMD hardware is required. For additional information see https://www.amd.com/en/graphics/amd-radeon-rx-laptops. GD-216.
4. Video codec acceleration (including at least the HEVC (H.265), H.264, VP9, and AV1 codecs) is subject to and not operable without inclusion/installation of compatible media players. GD-176
5. AMD Noise Suppression works on AMD Ryzen™ 6000 Series processors with integrated graphics, and AMD Radeon™ RX 6000 Series desktop graphics and newer. AMD Noise Suppression requires AMD Software: Adrenalin Edition™ 22.7.1 and newer and may not install on systems equipped with Realtek ACP-based ANR. GD-213
6. AMD HYPR-RX works on the AMD Radeon™ RX 7000 Series GPUs and newer or the Ryzen 7040 Series APUs with integrated RDNA 3 graphics and newer. AMD HYPR-RX allows various features within AMD Software interoperate, working at the same time, including Radeon Super Resolution, FidelityFX Super Resolution, Radeon Anti-Lag, Radeon Boost, and AMD Fluid Motion Frames where applicable to select titles. GD-225A.
7. Radeon™ Boost is compatible with Windows 10 and 11 in select titles only. Hardware compatibility includes RX 400 and newer consumer dGPUs, Ryzen 2000 and newer APUs, including hybrid and detachable graphics configurations. No mGPU support. Radeon™ Boost VRS compatible with AMD Radeon™ RX 6000 Series Graphics exclusively. For a list of compatible titles see https://www.amd.com/en/technologies/radeon-boost GD-158
8. Radeon™ Anti-Lag is compatible with DirectX 9, DirectX 11 and DirectX 12 APIs, Windows 10 and 11. Hardware compatibility includes Polaris and newer consumer dGPUs Ryzen 2000 and newer APUs, including hybrid and detachable graphics configurations. No mGPU support. GD-1579. AMD Fluid Motion Frames, or AFMF, is a frame generation technology designed to increase frame rates and smooth movement for game winning performance with minimal impact to image quality. AFMF is integrated into AMD Software and currently supports the Radeon RX 6000 and 7000 series graphics cards. GD-234
©2025 Advanced Micro Devices, Inc. All rights reserved. AMD, the AMD Arrow logo, AMD Radiance Display, AMD Smart Access Memory, RDNA, Ryzen, Radeon, and combinations thereof are trademarks of Advanced Micro Devices, Inc. Other product names used in this publication are for identification purposes only and may be trademarks of their respective companies.
製品仕様
メーカー情報 | |
---|---|
メーカー | XFX |
モデル番号 | RX-96TSW16BQシリーズ |
製品名 | AMD Radeon™ RX 9060 XT |
製品説明 | XFX Swift AMD Radeon RX 9060 XT OC Gaming Edition with 16GB GDDR6 HDMI 2xDP, AMD RDNA™ 4搭載 |
製品概要 | XFX Swift AMD Radeon RX 9060 XT OC Gaming Edition |
発売日 | 2025年6月 |
基本スペック | |
バスタイプ | PCI-E 5.0 |
ベースクロック | 最大 1900 MHz |
ゲームクロック | 最大 2780 MHz |
ブーストクロック | 最大 3320 MHz |
ストリームプロセッサ | 2048 |
コンピュートユニット | 32 |
メモリバス | 128bit |
メモリクロック | 20 Gbps |
メモリサイズ | 16 GB |
メモリ帯域幅 | 最大 340 GB/s |
実効メモリ帯域幅 | – |
メモリタイプ | GDDR6 |
カードサイズ | 2 スロット |
冷却ソリューション | 2連ファン |
出力端子 | |
DisplayPort 2.1 | 2ポート |
HDMI™ 2.1 | 1ポート |
HDCP | 対応 |
必要システム | |
外部電源 | 8ピン PCI-E 補助電源コネクタ ×1 |
推奨電源ユニット容量 | 450W |
認証 | |
RoHS | 適合 |
パッケージ内容 | |
クイックインストールガイド | ×1 |
寸法・重量(概算) | |
カード寸法 (cm) | 27 × 12.4 × 5.5 |
カード寸法 (inch) | 10.63 × 4.88 × 1.89 |
マスターカートン寸法 (cm) | 62 × 41 × 39 |
マスターカートン寸法 (inch) | 24.41 × 16.14 × 15.35 |
マスターカートン重量 | 15.19 kg / 33.49 lbs |
パッケージ寸法 (cm) | 36.5 × 19.8 × 12 |
パッケージ寸法 (inch) | 14.37 × 7.8 × 4.72 |
パッケージ重量 | 1.4 kg / 3.09 lbs |
製品重量 | 0.925 kg |
梱包入数 | 10個 |
搭載テクノロジー | |
RDNA™ 4 CU | 32基 (RT+AIアクセラレータ) |
AMD Infinity Cache™ | 対応 |
DisplayPort™ 2.1 | 対応 |
AMD Radiance Display™ | 対応 |
AMD Radeon™ Boost | 対応 |
AMD Radeon™ Anti-Lag | 対応 |
メモリ | 16 GB GDDR6 / 128-bit |
PCIe | Express 5.0 |
AMD FidelityFX™ | 各種テクノロジー (FSR 等) |
DirectX® 12 Ultimate | 対応 |
DirectStorage | 対応 |
Vulkan® | 最適化 |
AMD Software | Adrenalin Edition™ 他 |
AMD Noise Suppression | 対応 |
AMD Privacy View | 対応 |
AMD Radeon™ SR | Super Resolution 対応 |
AMD Link | 対応 |
AMD FreeSync™ | 対応 |
ゼロRPMモード | 対応 |
主な特徴 | |
HDMI™ 4K | 対応 |
4K H.264 | デコード / エンコード |
H.265/HEVC | デコード / エンコード |
AV1 | デコード / エンコード |
※「ゲームクロック」は一般的なTGPで想定されるGPUクロックです。実際の値はゲームによって異なります。 ※※「ブーストクロック」は高負荷時に達成可能な最大周波数で、熱条件やワークロードにより変動します。 |
